JC Casting is a China specialist manufacturer of Sand Casting parts and components. We have rich ​experience in manufacturing sand castings for different industries all over the world. We fully understand how to make sand casting to meet your demand and your industry.

We can cast sand casting parts up to 20 metric tons. The casting materials can be an aluminum alloy, ductile iron, gray iron brass alloy.We offer rapid prototype services, high precision CNC machining, secondary operations. Serviced industries including automotive, petrochemical, electrical, energy, transportation, mining.

We pride ourselves on our equipment and expertise to do any work efficiently and at a cost-effective price.

What Is Sand Casting?

Sand casting is also known as sand molded casting. It is a process that uses sand molds to form metal castings. Firstly, form a 3D pattern of sand by mold. Then pour the molten metal into the mold cavity for solidification. Finally, remove the sand shell to get the metal components cooled and formed. If needed, it can be a secondary machining process after casting.

Sand casting can cast almost any metal and alloy. Including iron, Carbon steel, Aluminum, alloy steel, titanium alloy. The weight range can be from a few ounces to tons. Sand casting is a cost-effective and efficient technology. Not only on casting size but also in a complicated geometry design.

What is Sand Castings Process

Step1: Mold-building

Creating a mold is the first step in the sand casting process. Each casting needs a mold. A sand mold is formed by putting the sand into each half of the mold. The sand is stacked around the pattern, which is a replica of the shape of the casting. When the pattern is removed, the cavity forming the casting remains. Any internal features of castings that cannot be formed by the pattern are formed by separate cores made of sand before forming the mold. Mold making time includes positioning patterns, packaging sand and remove the pattern. Mold manufacturing time by the size of components, the number of cores and the impact of sand. Lubricant is typically applied to the surface of the mold cavity to facilitate removal of the casting. The use of lubricants also improves the flow of the metal and can improve the surface finish of the castings. The lubricant used is selected based on the temperature of the sand and the molten metal.

Step 2: Pouring

After the mold is made, it must be prepared to pour the molten metal. First, the surface of the cavity is lubricated in order to remove the castings after casting. Then, the core is positioned and the mold halves are closed and securely clamped together. It is necessary to keep the mold half sealed to prevent any loss of material. The molten metal is kept at the set temperature in the furnace. After the mold is clamped, the molten metal can be cast from the holding vessel in the furnace and poured into the mold. Pouring can be done manually or by automated machines. Sufficient molten metal must be poured to fill the entire cavity and all channels in the mold. Filling time is very short, to prevent the early curing of any part of the metal.

Step 3 : Solidifying

Once poured into the mold, molten metal begins to cool and solidify. When the entire cavity is filled and the molten metal solidifies, the final shape of the casting is formed. Until the end of cooling time, the mold can be opened. The cooling time required can be estimated from the wall thickness of the casting and the temperature of the metal. Most of the possible defects are the result of the solidification process. If some molten metal cools too quickly, the part may shrink, crack or incompletely. Precautions can be taken when designing parts and molds.

Step4: Removal

After a predetermined set time, the sand mold can simply be broken and the castings removed. This step, sometimes referred to as getting rid of sand, is usually shaken by a vibrating machine and burned out of the bottle. Once removed, the castings may have some sand and oxide adhering to the surface. Blasting is sometimes used to remove residual sand, especially from the inside surface, and to reduce the surface roughness.

Step 5 : Cutting

During cooling, the material from the mold channels solidifies on the part. These extra material must be manually trimmed by cutting or sawing or using a trimming machine. The time it takes to trim excess material can be estimated from the size of the casting. Larger castings require longer dressing times. Waste from this trimming is discarded or reused during sand casting. However, it may be necessary to remediate appropriate chemicals for scrap before it is used in conjunction with non-recycled metals.

Advantages of Sand Casting

  • Wider material choice . Almost any ferrous and non-ferrous metals can be used
  • Weight and shape are vast
  • Low Cost of tools is
  • Small quantity or large quantity
  • Low cost for high volume parts
  • Short lead time

Advantages of Sand Casting Materials

Ferrous and non-ferrous materials are available for JC Sand Casting Process. Including: Aluminum Alloys Carbon Steel Steel (BS3100) Grey Iron (BS EN1561) Dutile Iron (BS EN 1563) Bronze Alloys。

Carbon SteelHigh Tensile SteelStainless Steel (304 & 306)
(A1. A2. A3. A4. A5 & A6)(BT1, BT2 &BT3)These two grades feature castability, corrosion re­sistant and weldability characteristics.

Grey Iron (BS EN1561)

  • Grade 150
  • Grade 200
  • Grade 250

Spheroidal Graphite Iron(BS EN 1563)

  • Grade 400/15
  • Grade 450/10
  • Grade 500/7
  • Grade 600/3
  • Grade 700/2

Red Brass

AlloyTensile Strength (ksi) Min./Typ.Yield Strength (ksi) Min./TypElongation (ksi) Min./Typ.Brinell hardness 10MM-500 (kg)

Yellow Brass

AlloyTensile Strength (ksi) Min./Typ.Yield Strength (ksi) Min./TypElongation (ksi) Min./Typ.Brinell hardness 10MM-500 (kg)

Tin Bronze, Silicon Bronze & Aluminum Bronze Alloys

AlloyTensile Strength (ksi) Min./Typ.Yield Strength (ksi) Min./TypElongation (ksi) Min.fTypBrinell Hardness 10MM-500 (kg)

Manganese Bronze

AlloyTensile Strength (ksi) Min./Typ.Yield Strength (ksi) Min./TypElongation (ksi) Min.fTypBrinell Hardness 10MM-500 (kg)
C86300 (424)110/12060/8318-Dec225
C99700 (T ombasil)60/7030/3516/20115

Secondary Operations of Sand Casting

  • Grinding, drilling, tapping, painting, shot blasting
  • High precision machining
  • Heat treatment
  • Assembly
